How do I communicate with XBee

XBee devices communicate with each other over the air, sending and receiving wireless messages. The devices only transfer those wireless messages; they cannot manage the received or sent data. However, they can communicate with intelligent devices via the serial interface.

How do I connect XBee modules?

Connect two XBee modules to your computer using the USB cables. …
Launch XCTU.
Click the Configuration working modes button .
Click the Discover radio modules button .
In the Discover radio devices dialog, select the serial ports where you want to look for XBee modules, and click Next.

How does Arduino communicate with XBee?

XBee is an RF module mainly used as a radio communication transceiver and receiver. It is mesh communication protocols, also XBee supports peer-to-peer as well as point to multi-point network communications wirelessly with the speed of 250 kbits/s, to operate XBee you need a transmitter and a receiver.

How far can XBee communicate?

XBee DeviceRangeProtocolXBee Pro 900 RPSMA (retired)6 MilesMulti-PointXBee Pro 900 U.FL Connection (retired)6 MilesMulti-PointXBee Pro 900 Wire Antenna (retired)6 MilesMulti-PointXBee Pro 900 XSC RPSMA (retired)15 MilesMulti-Point

What protocol does XBee use?

Xbee is the module using Zigbee protocol. Zigbee is a wireless communication protocol like wifi and bluetooth. ZigBee defines a network layer above the 802.15. 4 layers to support advanced mesh routing capabilities.

How do I use XBee USB adapter?

Simply plug the XBee 3 USB Adapter into the USB port of a laptop or PC for instant access to an Digi XBee network and its connected devices. This compact, USB-powered wireless adapter enables local network configuration, diagnostics or device monitoring. The XBee 3 USB Adapter can be programmed with Zigbee, 802.15.

How do I connect XBee to my computer?

Plug your XBee into your XBee Explorer, and plug the Explorer into your computer. …
Open XCTU. …
Hit Test/Query to make sure you can communicate with your XBee WiFi. …
Click over to the “Modem Configuration” tab. …
Select “Active Scan” near the top of the scrolling window.

What is DigiMesh?

DigiMesh simplifies network setup and reliability in environments where routers may come and go due to interference or damage. Battery Deployed Networks. Coordinators and routers must be mains powered. All nodes are capable of battery operation and can sleep.

What is XCTU?

XCTU is a free multi-platform application designed to enable developers to interact with Digi RF modules through a simple-to-use graphical interface. It includes new tools that make it easy to set-up, configure and test XBee® RF modules.

Why is XBee so expensive?

Zigbee devices are typically more expensive because they have to comply with various specifications from the Zigbee Alliance – giving rise to various subtle benefits compared to non-Zigbee devices.

Article first time published on

What is the difference between Zigbee and XBee?

XBee is a family of radio modules and is a registered trademark of Digi International. Zigbee is a wireless communications protocol and a registered trademark of the Zigbee Alliance. Many people confuse these two names because both are involved in radio networking and have “Bee” in their branding.

How do I connect Raspberry Pi to XBee?

So, before using the XBee modules with Raspberry Pi, we have to configure these modules using XCTU software. To connect XBee module with the laptop, a USB to serial converter or specifically designed explorer board is used. Just hook up the XBee module to the Explorer board and plug it with the laptop using USB cable.

How do I know if XBee is working?

Check cables. The USB cables should be firmly and fully attached to both the computer and the XBee development board. …
Check that the XBee module is fully seated in the XBee Grove Development Board. …
Check the XBee module orientation. …
Check that the XBee modules are in the same network. …
Restore default settings.

Is XBee a Bluetooth?

Your Digi XBee 3 radio module now has Bluetooth activated and will allow secure connections from the XBee Mobile application. You can leave the XBIB evaluation board connected to the computer for power, or change to a portable USB battery power supply to go fully wireless.

Which is better Zigbee or Bluetooth?

S.NOBluetoothZigbee5.Bluetooth requires low bandwidth.While zigbee also requires low bandwidth but greater than Bluetooth’s bandwidth most of time.

Is XBee open source?

The open source movement and strong maker community has led to the creation of a number platforms that give developers a quick and efficient way to create a proof of concept, prototype, or even a final product.

How do I connect my XBee to my laptop?

To connect XBee module with the laptop, a USB to serial converter or specifically designed explorer board is used. Just hook up the XBee module to the Explorer board and plug it with the laptop using USB cable.

Is XBee a WiFi?

As a member of the XBee family, the XBee WiFi combines hardware with software for a complete modular solution. XBee WiFi modules are designed to communicate with access points in existing 802.11 infrastructures. Developers can use AT and API commands for advanced configuration options.

How does Zigbee transmit and receive data?

In order to transmit or receive data on Xbee modules, they need to be properly configured on the same network. According to the Zigbee protocol one device needs to be in coordinator mode and the rest can be router or end devices. In this case, one device is coordinator and other is router.

How do I use XCTU terminal?

Click the Tools drop-down menu and select MicroPython Terminal. The terminal opens.
Click Open. If you have not already added devices to XCTU: …
Click OK. …
Press Ctrl+B to get the MicroPython version banner and prompt.

How do I download XCTU?

Go to
Click Download.
Under Download XCTU, click the Windows installer link.
Once the download is complete, run the executable file and follow the steps in the XCTU Setup Wizard.

How does ZigBee mesh work?

Mesh Networks A key component of the Zigbee protocol is the ability to support mesh networking. In a mesh network, nodes are interconnected with other nodes so that multiple pathways connect each node. Connections between nodes are dynamically updated and optimized through sophisticated, built-in mesh routing table.

What's better ZigBee or Z-Wave?

ZigBee operates at 2.4 GHz compared to the 908 MHz of Z-Wave. The higher frequency allows ZigBee to transmit more data but reduces the range of the signal. … A Z-Wave signal between two nodes can travel up to 330 feet in an outdoor, unobstructed setting.

Why ZigBee is better than WiFi?

ZigBee’s data transfer speed is lower than WiFi’s, too. It’s maximum speed is just 250kbps, much lower than the lowest speed WiFi offers. ZigBee’s best quality is its low power-consumption rate and battery life.

Do you need ZigBee?

They’re necessary because the protocols you’re more familiar with, such as Wi-Fi and Bluetooth, are rubbish for meshing together a lot of low power devices spread all around your home. A better solution was required, and Zigbee – along with Z-Wave – is the answer.

Can XBee transmit and receive at the same time?

Yes, it is possible to send and receive data at the same time. When XBee modules are configured in “AT mode” (also referred to as “Transparent Serial”), you configure the DH and DL parameters to identify the destination node that will receive the serial data.

How do I program Zigbee with Arduino?

Connect your zigbee’s module to computer serial port using serial adapter.
Download virtual terminal or PuTTy for windows.
set your computer serial port. …
click on local Echo box.
click ok.
save the time of session.

What is XBee shield?

The Xbee shield allows an Arduino board to communicate wirelessly using Zigbee. It is based on the Xbee module from MaxStream. The module can communicate up to 100 feet indoors or 300 feet outdoors (with line-of-sight). … The shields breaks out each of the Xbee’s pins to a through-hole solder pad.

What is a Zigbee module?

Zigbee is a low-cost, low-power, wireless mesh network standard targeted at battery-powered devices in wireless control and monitoring applications. Zigbee delivers low-latency communication. Zigbee chips are typically integrated with radios and with microcontrollers.

What is Zigbee transmitter and receiver?

ZIGBEE TRANSMITTER / RECEIVER SYSTEM. Description. The Z. 200 unit allows almost any number of analogue or digital input values to be wirelessly transmitted to a remote receiver with either analogue 4.20mA, 0.10V , Ethernet or RS232 outputs.

How do I program XBee pro?

Step 1: Download X-CTU Software. The X-CTU software is free to download and provides a simple interface to configure and update your XBee transceivers. …
Step 2: Put together your XBee breakout board. …
Step 3: Configure 1st XBee as a coordinator. …
Step 4: Configure 2nd XBee as Router. …
Step 5: Test the configuration.
