What is the OD of 12 2 MC cable

Cable TypeMC# of Conductors2 Conductors w/ GroundConductor MaterialBare CopperStranded or SolidSolidO.D. (Inches)0.477

What is the diameter of 4 3 MC cable?

Cable TypeMCWire Size4 AWG# of Conductors3 Conductors w/ GroundO.D. (Inches)0.941Ampacity95

What is the OD of 8 2 MC cable?

Cable TypeMC# of Conductors2 Conductors w/ GroundO.D. (Inches)0.69Ampacity55

What is the diameter of 6 3 MC cable?

Snap-In MC Connector for Aluminum and Steel MC, Material: Die-Cast Zinc, Cable Diameter 0.590″ to 0.920″, For the Following MC Sizes: 10/3, 10/4, 8/2, 8/3, 8/4, 6/2, 6/3.

What is OD in cable?

OD: The abbreviation for the “outside diameter” dimension that is used to measure the diameter of a cable. In general, as the wire gauge increases, so does the cable OD.

What sizes does MC cable come in?

MC Cable is available in in stranded or solid copper for sizes #14 AWG to #10 AWG and compact strand for sizes #8 AWG to #4/0 AWG. An optional outer PVC jacket is also available upon request.

What is the OD of 10 2 MC cable?

Cable TypeMCConductor MaterialBare CopperStranded or SolidSolidO.D. (Inches)0.544Ampacity30

What is MC cable?

MC Cable Definition MC Cable, by most common definition, is a factory assembly of one or more insulated circuit conductors enclosed in an armor of interlocking metal tape or a smooth or corrugated metal sheath.

What is the diameter of 14 2 MC cable?

Cable TypeMC# of Conductors2 Conductors w/ GroundConductor MaterialBare CopperStranded or SolidSolidO.D. (Inches)0.441

What is CU MC cable?

MC Cable is approved for power, lighting, control and signal circuits. MC Cable can be used in cable tray and other approved raceways and can be exposed or concealed. MC Cable can be used in places of assembly of 100 people or more, such as studios and theaters.

Article first time published on

How much does MC cable weigh?

0.470 250 1000 113 lbs.

What is armorlite cable?

Southwire Armorlite® Type MC Cable is constructed with soft-drawn copper, Type THHN/THWN conductors rated 90°C dry available in sizes 14 AWG through 2 AWG, and a green insulated grounding conductor. The conductors are cabled together and a binder tape bearing the print legend is wrapped around the assembly.

What does CL3R mean?

RatingUsageCMPAll in-wall, plenum and riser applications.CMR, CL3R, CL2RAll in-wall and riser applications; not permitted in plenums.CM, CMG, CL2In-wall rated; permitted in 1-2 family residential riser applications, or in riser with raceway/fireproof shaft; not permitted in plenums.

How do you calculate wire bundle diameter?

Divide the circumference by 3.1415 (pi). This will give you the diameter of the cable bundle. For the diameter of the hole, add a quarter of an inch to this number.

What is the diameter of 25mm2 cable?

Nominal Overall Diameter mmApprox Weight Kg/100mt16mm29.12125mm210.63035mm211.64050mm21352

Can you run MC cable outside?

These cables can be installed either indoors or outdoors and in exposed and concealed locations. They can be direct buried, where identified for such use. … Type MC cable with a nonmetallic jacket can also be used in a wet location.

Does MC cable need conduit?

Above Ground or Underground Romex should never be installed underground — the only NM cable that can be installed in this way is a UF-B cable. MC cable can be installed underground as long as it is run through a conduit to prevent decay. For above-ground applications, MC cable can be installed without a conduit.

Can MC cable be surface mounted?

New for the 2017 NEC Code-cycle is section 330.15, entitled “Metal-Clad Cable: Type MC Exposed Work.” This new Code section requires an exposed run of MC Cable to closely follow the surface to which it is mounted while enjoying a new permission that allows the MC cable to be installed on the underside of floor joists.

What is the diameter of 12 2 MC?

Cable TypeMC# of Conductors2 Conductors w/ GroundConductor MaterialBare CopperStranded or SolidSolidO.D. (Inches)0.477

How much does a thousand foot spool of 12 2 MC weigh?

Weight per 1000 ft: 160 lbs.

How many wires are in MC cable?

Metal-clad cable comes in several varieties, but the type you’ll find most commonly is three insulated wires (two circuit conductors and a green equipment grounding conductor) protected by a flexible armor usually made from aluminum. MC cable is identified by the gauge of the wire, not the diameter of the armor.

Where is MC cable required?

Type MC cable installed on the bottom of floor or ceiling joists must be secured at every joist and not be subject to physical damage [Sec. 330.15].

Is MC cable and armored cable?

MC cable is easier to remember because it’s an abbreviation for “metal clad” or “metallic-sheathed cable.” … Both are essentially just names for armored cable. When fiber is armored, it has a conductive jacket because the material is made from metal, usually aluminum or steel.

What metal is MC cable?

A Metal Clad Cable, also referred to as MC Cable, is a corrosion-resistant metal cable containing insulated copper or aluminum connectors.

What is MC Cable vs conduit?

Metal-clad armor resists corrosion, making it suitable for areas exposed to moisture. Interlocked armor is flexible, unlike conduit or even continuously welded armor, ensuring damage will not affect inner conductors. It is also more easily installed where complex, close-spaced bends would be difficult for conduit.

What is MC feeder cable?

Aluminum MC Feeder Cable For use in power, lighting, control and signal circuits and as branch circuits and power feeders in industrial, commercial, institutional and residential installations up to 600 volts.

How much does a 250 ft roll of 12 2 MC weight?

Brand NameSouthwireItem Weight5.20 poundsLength13.65 inchesLoad Capacity1 poundsMaterialAluminum

Who makes MC cable?

The newest and most innovative product launched by AFC Cable Systems is MC Luminary Cable Type MC-PCS* (U.S. Patent Pending) comes in two different versions: MC Tuff Luminary Cable and MC Lite Luminary Cable.

How many feet are in a roll of MC cable?

Covers 250 ft. (68¢ /ft.)

How often does MC cable need to be supported?

According to NEC Article 330.30, MC cable must be supported and secured at intervals of 6 feet or less (unless routed through a framing member) and cables containing four or fewer conductors sized no larger than 10 AWG must be secured within 12 inches of every termination.
